1,500 VDC Combiner
Combiner Boxes are designed to take multiple circuits and combine them in a single output.
DC Sun Volt offers a variety of options, various types of NEMA rated Enclosures, Surge suppressors, double output lugs and more. Up to 36 circuits at 1,500 VDC.
Options
✔ Load Break Disconnect
✔ Grounded or Ungrounded configurations
✔ Custom Versions
✔ Rated up to 400 Amps
✔ 4 up to 36 Strings
✔ Surge Protection Device
✔ NEMA Type: 3R / 4 / 4X Enclosures
✔ Dual Output lugs
Technical Specifications
| Specification | Model A | Model B | Model C |
|---|---|---|---|
| Disconnect Ampacity | 275 Amps | 325 Amps | 400 Amps |
| Number of Circuits | 18 | 28 | 36 |
| Input Wire Size | 14 – 8 AWG | 14 – 8 AWG | 14 – 8 AWG |
| Max Fuse Size | 30 Amps | 30 Amps | 30 Amps |
| Number of Outputs | 1 or 2 | 1 or 2 | 1 or 2 |
| Output Wire Size | 6 – 350 Kcmil | 2 – 600 Kcmil | 2 – 600 Kcmil |
| Metal Enclosure Type 3R/4 | 24x24x8 | 30x24x8 | 30x30x8 |
| Type 4X Enclosure | 24x24x8 | 30x24x8 | 36x30x8 |
Custom configurations available. Contact our engineering team for pricing and project-specific requirements.
