DC Sun Volt

750VDC RAPID SHUTDOWN

750VDC RAPID SHUTDOWN

$297.00 USD
$297.00 USD
Sale Sold out
Select your product
View full details

750VDC RAPID SHUTDOWN

Professional 2 & 4 String Configuration

🏠

Perfect For

Residential and small commercial solar installations requiring 750VDC rating. Ideal for medium-sized systems with 2 string configurations.

💰

Cost-Effective

Optimized for smaller installations while maintaining all professional features and certifications. Best value for 2-string systems.

Product Features



✅ Certification & Safety

  • • Rated 750VDC
  • • Certified to UL508
  • • NEMA Type 4X Enclosure

⚙️ Technical Features

  • • Integrated Load Break Contactors
  • • Lock out tag out control circuit
  • • Ground Strip Included

🔌 Configuration

  • • 2 POS / 2 NEG Inputs/Outputs
  • • 20 Amps load break
  • • 50 Amps continuous

📊 Technical Specifications


Power Ratings

Maximum Voltage: 750 VDC

Max Rated Current: 20 Amps

Continuous Current: 50 Amps

Circuit Configuration

Input Circuits: 2 POS / 2 NEG

Output Circuits: 2 POS / 2 NEG

Wire Size: 22 - 8 AWG

System Details

Enclosure: NEMA Type 4X

Controls Circuit: 24 VDC

Product Type: Pass-Through Unit


🏆 Why Choose DC Sun Volt?

🔧

Easy to replace components

⚡

Make and Break DC Resistive Load

🛡️

Multiple NEMA enclosure types available

📞

Professional technical support

Compliance: NEC 690.12 |Certification: UL508 |Warranty: Professional Grade

Why Choose DC Sun Volt?

Compliance: NEC 690.12 | Certification: UL508 | Warranty: Professional Grade

🔧 Easy to replace components
⚡ More durable than solid state systems
🛡️ Multiple NEMA enclosure types available
📞 Professional technical support
