DCSunVolt

[3 String] Rapid Shutdown 1,000VDC

[3 String] Rapid Shutdown 1,000VDC

$1,195.00 USD
$1,195.00 USD
Sale Sold out

1000VDC RAPID SHUTDOWN

3 String Configuration

Part No. PV4X-U6S-RS

šŸ  Perfect For

Residential and commercial solar systems requiring 3-string configurations. Designed to be installed within 10 feet of the array (per NEC 690.12).

šŸ’” Smart Choice

Any String Quantity. Make and Break DC Resistive Load ā€” 20 or 33 Amps @ 1,000VDC. NEMA type enclosures 3R, 4, and 4X available. Easy to replace components.

šŸ”§ Product Features

āœ“ Certification & Safety

  • Rated 1,000VDC
  • Certified to cETLus to UL1741
  • NEMA Type 4X Enclosure

āš™ Technical Features

  • Configurations for Negative and Positive Inputs
  • Ground Strip Included
  • Continuous Current 50 Amps

šŸ”Œ Configuration

  • 3 POS / 3 NEG Inputs/Outputs
  • 20 Amps load break
  • 50 Amps continuous

šŸ“Š Technical Specifications

Maximum Voltage: 1,000 VDC

Max Rated Current: 20 Amps

Continuous Current: 50 Amps

Input Circuits: 3 POS / 3 NEG

Output Circuits: 3 POS / 3 NEG

Wire Size: 22 ā€“ 8 AWG

Enclosure Size: 14x12x6

Enclosure NEMA Type: 4X

Controls Circuit: 24 VDC

šŸ† Why Choose DC Sun Volt?

šŸ”§ Easy to replace components

āš” More durable than solid state systems

šŸ›” Multiple NEMA enclosure types available (3R, 4, 4X)

šŸ“ž Professional technical support

Compliance: NEC 690.12 | Certification: Certified to cETLus to UL1741 | Part No.: PV4X-U6S-RS | Product Type: Pass-Through Unit
