DC Sun Volt

[5 String] RAPID SHUTDOWN 1,000VDC

[5 String] RAPID SHUTDOWN 1,000VDC

$1,825.00 USD
$1,825.00 USD
Sale Sold out

1000VDC RAPID SHUTDOWN

5 String Configuration

Part No. PV4X-U10S-RS

šŸ¢ Perfect For

Commercial and large residential solar installations requiring five-string configurations with 1,000VDC rating.

šŸš€ Maximum Output

Built for high-demand commercial systems. Engineered for reliability, safety, and long-term performance at scale.

šŸ”§ Product Features

āœ“ Certification & Safety

  • Rated 1,000VDC
  • Certified to cETLus to UL1741
  • NEMA Type 4X Enclosure

āš™ Technical Features

  • Integrated Load Break Contactors
  • Lock out tag out control circuit
  • Ground Strip Included

šŸ”Œ Configuration

  • 5 POS / 5 NEG Inputs/Outputs
  • 20 Amps load break
  • 50 Amps continuous

šŸ“Š Technical Specifications

Maximum Voltage: 1,000 VDC

Max Rated Current: 20 Amps

Continuous Current: 50 Amps

Input Circuits: 5 POS / 5 NEG

Output Circuits: 5 POS / 5 NEG

Wire Size: 22 ā€“ 8 AWG

Enclosure Size: 18x16x10

Enclosure NEMA Type: 4X

Controls Circuit: 24 VDC

šŸ† Why Choose DC Sun Volt?

šŸ”§ Easy to replace components

āš” More durable than solid state systems

šŸ›” Multiple NEMA enclosure types available

šŸ“ž Professional technical support

Compliance: NEC 690.12 | Certification: Certified to cETLus to UL1741 | Part No.: PV4X-U10S-RS
